Face Terminals

FCV4906

Android face terminal

Bring your Android application to the door.

An 8-inch Android 11 terminal for face authentication and on-device applications. Select memory, networking and mounting around the software you plan to deploy.

  • Android 11
  • 8-inch touch display
  • Ethernet & Wi-Fi
FCV4906 illustrated at a modern office entrance

Android flexibility.
Everyday access.

An 8-inch Android terminal for custom staff, member and visitor interactions.

Display
8-inch
Platform
Android 11
Credentials
Face, QR & card options
Connections
Ethernet, Wi-Fi, RS485/232, USB

Application illustration. Functions depend on configuration.

Technical specifications.

FCV4906

Functions, interfaces and mounting accessories depend on the selected configuration. Confirm them with the evaluation unit.

FCV4906 specifications
Operating systemAndroid 11
Display8-inch LCD touch screen
ProcessorQuad-core 64-bit Cortex-A55 · up to 2.0 GHz
Memory2 GB / 4 GB configurations
Storage16 GB; 32 GB / 64 GB expansion options
ConnectivityEthernet and 2.4 GHz Wi-Fi; 4G is optional
More specifications
FCV4906 additional specifications
Host interfacesRS485 / RS232, USB and relay; confirm the selected interface configuration
Power input9–24 V DC · 12 V recommended

Certifications

  • CE (RED 2014/53/EU)HK2511106100EShenzhen HUAK
  • FCC ID2BPI7-FCV4906MiCOM LabsVerify
All FCV4906 records on the certifications page
FCV4906 shared-housing mounting illustration with an 86-type electrical box
FCV4906 · 86 box installation

A familiar fit.
An Android platform.

Wall mounting uses the shared housing arrangement shown, with a mounting plate and an 86-type electrical box. Follow the FCV4906 manual for wiring and the supplied assembly.

  • Match the mounting assembly to this device version.
  • Keep the camera clear of the door or gate movement.
  • Leave room for rear wiring and service access.
View installation reference

Shared-housing mounting illustration. Use the FCV4906 installation drawing for dimensions and wiring.

FCV4906 wall-mount configuration and pictured accessories

Wall-mount kit.

A compact arrangement for the entrance wall.

  • Terminal & mounting components
  • Pictured terminal connectors
  • Mounting fasteners

Supplied accessories and quantities depend on the selected order. Confirm the packing list with our team.

FCV4906 pedestal-mount configuration and pictured accessories

Pedestal-mount kit.

An elevated arrangement for gates and reception surfaces.

  • Terminal & pedestal assembly
  • Pictured power and cable components
  • Connectors & mounting fasteners

Supplied accessories and quantities depend on the selected order. Confirm the packing list with our team.

Your questions, answered.

What lighting conditions should we consider?

Strong backlight, direct sunlight, reflections and close-range lighting can reduce capture quality. Evaluate the terminal in its intended position and avoid pointing the camera directly toward a bright window or concentrated light source.

What kind of enrollment photograph should we use?

Use a clear, front-facing JPG without beauty filters, heavy makeup, sunglasses, a mask or other facial obstruction. File size and image dimensions can vary by software and model, so confirm the current import requirements before preparing a large enrollment set.

What should we confirm before connecting a face terminal to the network?

Confirm whether your configuration uses wired networking, Wi-Fi or another connection. Collect the network and platform settings for that system. Local network access does not prove a management-service connection. Check both states separately, using the matching setup reference.
